Product Details:
Payment & Shipping Terms:
|
Precision Rating: | P0 P6 P5 | Seals Type: | Double Sealed |
---|---|---|---|
Material: | 42CrMo,50Mn | Teeth: | Internal Teeth |
Rolling Element: | Ball | Lubrication: | Grease Oil Hole |
Load: | Heavy Load | Heat Treatment: | Q+T |
Slewing Ring Bearings RK6-22P1Z 25.51X17.09X2.2 inch size
Slewing Ring Bearings RK6-22P1Z with size 25.51X17.09X2.2inch size consist of two ring seats. Compact structure, light weight, steel ball and arc track contact at four points, can bear axial force, radial force and overturning moment at the same time, has strong dynamic load.
Slewing ball bearing Model NO.:RK6-22P1Z
The bearing full size :25.51X17.09X2.2 inch
The bearing outer diameter:25.51 inch size
The bearing inner diameter:17.09 inch size
The bearing total height:2.2 inch size
The bearing tolerance:+/-0.4mm
The bearing structure:single row four point contact ball bearing with doulbe flange
The bearing boundary dimension :25.51X17.09X2.2 inch
The bearing outside diameter:648mm
The bearing inner diameter:434mm
The bearing total height:55.88mm
The bearing ring material:42CrMo,50Mn available
Seal:sealed on both side
Flange:two rings with flange
Ball material:GCr15 steel
HS Code:8482100090
MOQ:2 PCS
Package: wooden case
Teeth:without teeth
Slewing Ring Bearings RK6-22P1Z main used for Ladle turret,Stacker crane,Bucket wheel machine,Solar heliostat Tracking System,port crane, Cabling machine,tower crane , offshore platform,ferris wheel, Palletizing robot,Rotary metallurgical furnace,can packing machine,Wind blade transporter,shield tunneling machine,tube push bench,excavator
