Pinion gear 64x25x50mm ,matched with slewing bearing with gear，42CrMo material,in stock

Large Image : Pinion gear 64x25x50mm ,matched with slewing bearing with gear，42CrMo material,in stock

Product Details:

Place of Origin:	China LuoYang
Brand Name:	JHB or OEM
Certification:	ISO9001:2008 or Quality certificate
Model Number:	pinion gear

Payment & Shipping Terms:

Minimum Order Quantity:	1pcs
Price:	Negotiated
Packaging Details:	standard export package
Delivery Time:	in stock ,if ex-stock,It will need 20-30 days
Payment Terms:	T/T,L/C
Supply Ability:	1000 PCS/Month

Contact Now

Detailed Product Description

Material:	42CrMo	Heat Treatment:	55-64 HRC
Gear:	Helical Gear	Package:	Wooden Case
Quality Standard:	GB307

Pinion gear 64x25x50mm ,matched with slewing bearing with gear,42CrMo material

The pinion specification as following:

Pinion dimension	64x25x50mm
Out dia	Φ64 mm
Inner dia	Φ25 mm
height	Φ50 mm

The pinion material:42CrMo

The pinion heat treatment:

The forging hardness of hardening and tempering:HB229-269

The gear hardness of quenching:HRC40-50

The pinion teeth parameter as following:

The module:4

No of teeth:14

Press angle: 20 degree

If you want to learn more, you can tell us your required technical data,we will design the drawing for you according to offer.

The delivery time about 20 days.

The pinion gear including spur gear and helical gear and herringbone gear.Also welcome your customized.

We/JinHang Precision bearing offer pinion ,spare parts,slewing bearing,turntable bearing,swivel bearing,slewing ring,They are used in heavy industry equipment.

The package: standard wooden case.

Pinion gear 64x25x50mm ,matched with slewing bearing with gear，42CrMo material,in stock

JinHang Precision pinion gear advantage:
1.Multidirectional load/high rigidity
2.high precision
3.Used in Heavy duty equipment
4.Short delivery time
5.Standard export wooden case package
6.Super original forging
