High precision ball bearing 718/670M for Cage-type stranding machine
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Precision Rating: | P4 P5 | Cage Material: | Brass Or Nylon |
|---|---|---|---|
| Number Of Row: | Single Row | Application: | Main Spindle Shaft |
High precision ball bearing 718/670M for Cage-type stranding machine
Code Explanation
- 718: Ultra-thin wall, ISO 18 dimension series, single-row angular contact structure
- /670: Bore diameter = 670 mm
- AC: 25° contact angle
- M: Solid brass (copper alloy) machined cage
- P4: Super precision grade (ISO P4 / ABEC7), strict dimensional & running accuracy
Key Specifications
- Bore: 670 mm
- OD: 820 mm
- Width: 69 mm
- Contact angle: 25°
- Structure: Open type, single row
- Material:High quality steel GCr15SiMn
- Heat treatment: HRC58-62
- The delivery time: in stock
- Stock qty:50pcs
- HS code:8482103000
Application
Ideal for large precision rotary equipment: cable stranding machines (your shown machine), large rotary tables, radar turntables, CT rotary frames, large optical scanning turntables and heavy-duty precision spindles. Usually used in matched sets (DB / DF / DT arrangement) for bidirectional axial positioning.
