Medium Steel Wire Rope Machine Use Roller Bearing Z-549128.ZL

Large Image : Medium Steel Wire Rope Machine Use Roller Bearing Z-549128.ZL

Product Details:

Place of Origin:	China
Brand Name:	JHB or your required
Certification:	Quality certificate
Model Number:	Z-549128.ZL

Payment & Shipping Terms:

Minimum Order Quantity:	2pcs
Price:	1000-10000USD
Packaging Details:	Carton or standard export wooden case
Delivery Time:	60 days
Payment Terms:	T/T,L/C, Western Union
Supply Ability:	1000PCS/MONTH

Contact Now

Detailed Product Description

Material:	GCr15SiMn	Cage Material:	Brass/steel
Clearance:	C1 C2 C0 C3 C4	Precision Grade:	P5 P6
Application:	Tubular Strander Machine	Feature:	High Rigidity, High Radial Load Carrying Capacity

Medium steel wire rope machine use roller bearing Z-549128.ZL

Single row cylindrical roller bearings Z-549128.ZL with cage are units comprising solid inner and outer rings and cylindrical roller and cage assemblies.The cylindrical roller bearings have high rigidity, high radial load carrying capacity and, due to the cage, are suitable for higher speeds than full complement designs.The bearings z-549128.zl are separable and are therefore easier to mount and dismount. As a result, both bearing rings can be given a tight fit. Single row cylindrical roller bearings with cage are available as non-locating, semi-locating and locating bearings.

Medium Steel Wire Rope Machine Use Roller Bearing Z-549128.ZL

Bearing items: 541924

Bearing boundary size 190*340*114mm

Bearing outer diameter:340MM

Bearing inner diameter:260MM

Bearing height :114mm

Internal structure: Single row cylindrical roller bearing

Rolling: Roller

Basic dynamic load rating, Radial Cr:1250KN

Basic static load rating, Radial Cor:2850KN

Ring material: steel GCr15SiMn

Roller material:steel GCr15

Cage material: Brass

Precision grade:P5 P6 Available

Application: Wire cable steel rope Tubular Strander machine

Delivery time 60 days

Service:offer drawing and guarantee quality.

We/LuoYang JinShuo Precision Bearing can offer cylindrical roller bearing,tapered roller bearing,slewing bearing,tandem roller bearing,crossed roller bearing,turntable bearing with high precision bearing.Also can offer standard size and non standard size.
