RB12016UUCC0 Crossed roller bearing 120x150x16mm application for swiveling table machine tool,in stock

Large Image : RB12016UUCC0 Crossed roller bearing 120x150x16mm application for swiveling table machine tool,in stock

Product Details:

Place of Origin:	China LuoYang
Brand Name:	JHB or OEM
Certification:	ISO9001:2008 or Quality certificate
Model Number:	RB12016UUCC0

Payment & Shipping Terms:

Minimum Order Quantity:	1pcs
Price:	Negotiated
Packaging Details:	standard export package
Delivery Time:	in stock ,if ex-stock,It will need 20-30 days
Payment Terms:	T/T,L/C
Supply Ability:	1000 PCS/Month

Contact Now

Detailed Product Description

Precision Rating:	P5 P6 P0	Seals Type:	No Seal
Number Of Row:	Single Row

RB12016UUCC0 Crossed roller bearing 120x150x16mm application for swiveling table machine tool,in stock

RB12016UUCC0 Bearing feature:
RB12016UUCC0 belong to THK Crossed roller bearing RB series. As a result of limited space inner ring and outer rings,Its outer ring structure is separable while the inner ring is integrated .The RB12016UUCC0 used for high rotation accuracy machine tool .It is typical and common crossed roller bearing structure.

RB12016UUCCO bearing specification:

name	Crossed roller bearing RB12016UUCC0
Boundary dimension:	120x150x16 MM
Outer dia:	150mm
Inner dia:	120mm
width	16mm
Radial basic loading	C:24.4KN
Radial basic loading	C0:43KN
Weight	0.72KGS
UU	With seal attached on both sides
CCO	Negative clearance,preload
Package	vacuumize

RB12016UUCC0 Bearing application:
Industrial robots,swiveling tables of machining centers,Precision rotary tables,medical equipment,measuring instruments and IC manufacturing machines.

RB12016UUCC0 Crossed roller bearing 120x150x16mm application for swiveling table machine tool,in stock

RB12016UUCC0 Bearing process flow:
Rough lath,soft lath,heat treatment process,rough grinding,soft grinding,assembly process,fully inspect,keep record,package,order vessels,shipping to customer.

We/JinHang Precision mainly offer RB Series,RE Series,RU Series,XU series,SX Series,CRBH Series,CRB Series,RA Crossed roller bearing series. Meanwhile we can offer YRT Rotary table bearing, XR/JXR Crossed tapered roller bearing.
