XU060111 Crossed roller slewing bearing no gear,XU060111 slewing ring supplier

Here thanks for help. We had got the bearing and checked them. After the working,they are working perfect. I will be keep you in mind !

—— Mr Scott

I'm Online Chat Now

XU060111 Crossed roller slewing bearing no gear,XU060111 slewing ring supplier

China XU060111 Crossed roller slewing bearing no gear,XU060111 slewing ring supplier supplier
XU060111 Crossed roller slewing bearing no gear,XU060111 slewing ring supplier supplier XU060111 Crossed roller slewing bearing no gear,XU060111 slewing ring supplier supplier XU060111 Crossed roller slewing bearing no gear,XU060111 slewing ring supplier supplier XU060111 Crossed roller slewing bearing no gear,XU060111 slewing ring supplier supplier

Large Image :  XU060111 Crossed roller slewing bearing no gear,XU060111 slewing ring supplier

Product Details:

Place of Origin: China LuoYang
Brand Name: JHB or OEM
Certification: ISO9001:2008 or Quality certificate
Model Number: XU060111

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: Negotiated
Packaging Details: standard export package
Delivery Time: in stock ,if ex-stock,It will need 20-30 days
Payment Terms: T/T,L/C
Supply Ability: 1000 PCS/Month
Contact Now
Detailed Product Description
Precision Rating: P5 P6 P0 Seals Type: Double Seal Rubber
Number Of Row: Single Row

XU060111  Bearing  XU060111 crossed roller slewing bearing no gear

teeth  technology parameter as follow:



Description

XU060111  crossed roller slewing bearing

Outside and Inside diameter tolerances

in accordance with ISO2768-m

dimension

145.79x76.2x15.87 mm

Outer diameter(OD)

145.79 mm

Inner diameter(ID)

76.2mm

Width/Height/(H)

15.87 mm

Axial Ca

56 KN

Axial Cor

53 KN

Radial Ca

35.5 KN

Radial Cor

26 KN

Material

42CrMo,42CrMo4V,50Mn

Package

Inside package: plastic film + kraft paper + blue tape;

Outside package: standard export free-fumigation wooden case.





XU060111 crossed roller bearings structure description

XU060111  Crossed roller bearings are units comprising inner and outer rings with a closing plug and securing dowel, rolling elements, spacers, contact seals and lubrication nipples.
1.gear teeth on the outer ring, inner ring or without gear teeth.
2.bearing rings with through holes or threaded holes for fixing screws
3.are suitable for circumferential speeds
4.can support high radial loads,moderate axial loads and tilting moment loads.
5.are suitalbe for operating temperatures from -25 ℃ to +80 ℃



XU:Crossed roller bearing, without gear teeth, preloaded, sealed, lubrication nipple on circumference

of ring without teeth

Crossed roller bearing without gear teeth series XU:

XU060111 Crossed roller slewing bearing no gear,XU060111 slewing ring supplier



Designation

Weight

(kgs)

Dimension (mm)

Basic load ratings (KN)





Da

di

H

Axial

Ca

Axial

Coa

Radial

Cr

Radial

Cor

XU050077

1.4

112

40

22

22.4

29

14.3

14.2

XU060094

 2.4

140

57

26

32.5

37.5

20.7

18.4

XU060111

 1.2

145.79

76.2

15.87

36

44.5

22.8

21.5

 XU080120

 4

170

69

30

56

53

35.5

26

 XU080149

 3.6

196.85

101.6

22.22

63

66

40

32.5

XU120179

 7

234

124.5

35

118

179

75

88



XU060111   Bearing,  XU060111  Slewing ring,XU060111  crossed roller slewing bearing Application:

Foundry operation

Construction machinery (e.g. crane, dragline excavator, vibratory roller)

Vehicles and vehicle attachments (e.g. lorry-mounted crane)

Fork lift trucks and fork lift truck attachments

Sewage treatment plant

Wind power equipment

Robots

Antennae

Machine tools

Measuring equipment

Medical equipment

JinHang Precision Bearing mainly  export high quantities   XU060111   Slewing Bearing and relative products, we have huge stocks for  XU060111    slewing ring  and relative items, we supply high quality  XU060111   four point contact ball  Bearing with reasonbable price or we produce the bearings along with the technical data or relative drawings, It's priority to us to supply best service to our clients. If you are interested in  XU060111   Bearing, please email us :lyjh@lyjhbearing.com    so we will contact you directly.
