Home ProductsSpherical roller thrust bearing

293/600 spherical roller bearing,600X800x122 mm, GCr15SiMn Material,brass cage

Here thanks for help. We had got the bearing and checked them. After the working,they are working perfect. I will be keep you in mind !

—— Mr Scott

I'm Online Chat Now

293/600 spherical roller bearing,600X800x122 mm, GCr15SiMn Material,brass cage

China 293/600 spherical roller bearing,600X800x122 mm, GCr15SiMn Material,brass cage supplier
293/600 spherical roller bearing,600X800x122 mm, GCr15SiMn Material,brass cage supplier 293/600 spherical roller bearing,600X800x122 mm, GCr15SiMn Material,brass cage supplier

Large Image :  293/600 spherical roller bearing,600X800x122 mm, GCr15SiMn Material,brass cage

Product Details:

Place of Origin: China
Brand Name: JHB
Certification: ISO9001:2008
Model Number: 293/600

Payment & Shipping Terms:

Minimum Order Quantity: 1PCS
Price: 1-1000USD/negotiation
Packaging Details: Carton or standard export wooden case
Delivery Time: in stock or ex-stock
Payment Terms: T/T,L/C
Supply Ability: 1000 pcs/month
Contact Now
Detailed Product Description
Precision Rating: P5 P6 P0 Seals Type: No Seal
Number Of Row: Single Row

Description: Spherical roller thrust bearing

Type: 293/600  Spherical roller thrust bearing

Dimension: 600X800X180 mm/Metic

ID(inner diameter)/Bore: 600 mm

OD(outer diameter):900 mm

Width/Height/thickness:180 mm

Quantity: One Bearing

The Number or roller: One

Lubrication: Oil or Grease

The forging material:GCr15SiMn  GCr15, Chrome steel

The cage type: brass cage or steel cage



Basic Dimensions(mm)

Bearing Designations

Precision Rating

basic load rating(KN)

Weight

(KGS)

d

D

B

C

Co

600

900

180

293/600

 P5 P6 P0

  7530

 34500

    405

The 293/600  Spherical roller thrust bearing  can carry combined loads which is main in axial and axial loads in one direction. Their loading capacity and limiting speed are high, and they can align by themselves when the precision of shafts or housings is not high or there is installation error.
 The 293/600 Spherical roller thrust bearing will working application:  Metalworking,Plastics, Marine, Industrial gearboxes, Pulp&Paper,Material Handling,Fluid machinery, Mining&construction, Blowout preventers, Classifiers, Extruders, Metal mill work/back-up rolls, Pre-heater fans, Pumps, Screw conveyors
heavy vertical shafts, , injection moulding machines,
Power Generation / Wind Turbines, Steel rolling / heavy industry / Transmissions
Agricultural and so on
