Home ProductsFour point contact ball slewing bearing

offer E.950.20.00.B Four point contact Slewing bearing 950.1X772XD56 mm in stocks price and stocks

Here thanks for help. We had got the bearing and checked them. After the working,they are working perfect. I will be keep you in mind !

—— Mr Scott

I'm Online Chat Now

offer E.950.20.00.B Four point contact Slewing bearing 950.1X772XD56 mm in stocks price and stocks

China offer E.950.20.00.B   Four point contact Slewing bearing  950.1X772XD56 mm in stocks price and stocks supplier
offer E.950.20.00.B   Four point contact Slewing bearing  950.1X772XD56 mm in stocks price and stocks supplier offer E.950.20.00.B   Four point contact Slewing bearing  950.1X772XD56 mm in stocks price and stocks supplier offer E.950.20.00.B   Four point contact Slewing bearing  950.1X772XD56 mm in stocks price and stocks supplier offer E.950.20.00.B   Four point contact Slewing bearing  950.1X772XD56 mm in stocks price and stocks supplier

Large Image :  offer E.950.20.00.B Four point contact Slewing bearing 950.1X772XD56 mm in stocks price and stocks

Product Details:

Place of Origin: China
Brand Name: JHB or your required
Certification: ISO9001:2008
Model Number: E.950.20.00.B

Payment & Shipping Terms:

Minimum Order Quantity: 1PCS
Price: 1-1000USD/negotiation
Packaging Details: Carton or standard export wooden case
Delivery Time: in stocks
Payment Terms: T/T,L/C, Western Union
Supply Ability: 1000 pcs/month
Contact Now
Detailed Product Description
Precision Rating: P0 P6 P5 Seals Type: Double Sealed
Delivery Time: In Stocks Bearing Type: E.950.20.00.B



offer E.950.20.00.B Four point contact Slewing bearing 950.1X772XD56 mm in stocks price and stocks





E.950.20.00.B belongs to TGB Four point contact Slewing bearing code, external gear teeth, selectable internal clearance, sealed, lubrication nipple on circumference of ring without teeth.We can replace the E.950.20.00.B slewing bearing . with lower price and reliable quality shorter delivery time we can get the approval from old customer

In order to meet the customer requirement, we had prepared the slewing bearing E.950.20.00.as stocks to decrease the delivery time. You can choose the shipping sea or by aire terms.

Now the VSA200844N Slewing bearing details as following:



Slewing bearing type E.950.20.00.B
Boundary size 950.1X772XD56 mm
Outer dia: 950.1 mm
Inner dia: 772 mm
Height 56mm
Gear teeth parameter:
Gear teeth external gear teeth
Press angle 20 degree
m 8
z 117
Heat treatment Forging normalization hardness:HB187-241
Package Standard strong wooden case
Delivery time In stocks




For slewing bearing E.950.20.00.B Preventive maintenance:
Leak tightness check
Judge whether the seal ring is intact by visual inspection:
a) No excessive stretch or damage
b) Positioned correctly
c) Rub the wear beside the lip
Please replace the sealing element, if necessary. After re-lubricating, wipe out the old grease
and check whether there is any pollutant such as sand, coal dust or metal particle.





offer E.950.20.00.B   Four point contact Slewing bearing  950.1X772XD56 mm in stocks price and stocks



E.950.20.00.B  Slewing bearings perform extremely well in a variety of applications such as:
• access platforms
• bucket wheel excavators
• conveyor booms
• cranes of all types
• small, medium and large excavators
• indexing tables
• ladle turrets
• offshore applications
• robots
• railway bogies
• rotary platforms
• stackers
• solar mirrors
• tunnel boring machines
• wind turbines





For the slewing bearing/slewing ring  E.950.20.00.B ,If you need it ,Please contact us as following:
