China slewing Bearing factory offer 013.32.1405 four point contact ball slewing bearing,15253X1235X119mm

Here thanks for help. We had got the bearing and checked them. After the working,they are working perfect. I will be keep you in mind !

—— Mr Scott

I'm Online Chat Now

China slewing Bearing factory offer 013.32.1405 four point contact ball slewing bearing,15253X1235X119mm

China China slewing Bearing factory offer 013.32.1405 four point contact ball slewing bearing,15253X1235X119mm supplier
China slewing Bearing factory offer 013.32.1405 four point contact ball slewing bearing,15253X1235X119mm supplier China slewing Bearing factory offer 013.32.1405 four point contact ball slewing bearing,15253X1235X119mm supplier China slewing Bearing factory offer 013.32.1405 four point contact ball slewing bearing,15253X1235X119mm supplier China slewing Bearing factory offer 013.32.1405 four point contact ball slewing bearing,15253X1235X119mm supplier

Large Image :  China slewing Bearing factory offer 013.32.1405 four point contact ball slewing bearing,15253X1235X119mm

Product Details:

Place of Origin: China
Brand Name: JHB or OEM
Certification: ISO9001:2008
Model Number: 013.32.1405

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: USD2000/PCS
Packaging Details: Strong wooden case
Delivery Time: 40 DAYS
Payment Terms: T/T, Western Union
Supply Ability: 500PCS/MONTH
Contact Now
Detailed Product Description
Material: 50Mn 42CrMo Delivery Time: 40 Days
Package: Strong Wooden Case Gear: Internal Gear

China slewing Bearing supplier offer 013.32.1405 four point contact ball slewing bearing with internal gear ,15253X1235X119mm



How to choose the right slewing bearing type 013.32.1405?it will based on the following bearing data:
1.applied loads
2.Collective loads with respective time percentages
3.Speed or number of movements and angle per time unit together with the relating collective loads
4.Circumferential forces to be transmitted by the greasing
5.Bearing diameter
6.Other operating conditions



013.32.1405 slewing bearing parameter:

Bearing type 013.32.1405
Boundary dimension 1525x1235x119mm
Outer dia: 1525mm
Inner dia: 1235mm
Height: 119mm
Teeth : Internal teeth
No.of teeth 90
Module 14
Press angle 20 degree



China slewing Bearing factory offer 013.32.1405 four point contact ball slewing bearing,15253X1235X119mm

The slewing bearing delivery time: about 40 days after getting the order
The material :50Mn or 42CrMo available
Package:standard strong wooden case,suiting for long shipping trip


013.32.1405 slewing ring feature:
Can support high dynamic loads,transmitting axial and radial forces simultaneously as well as the resulting tilting moments.



013.32.1405 slewing bearing application:
Hoisting,mechanical handle and general mechanical engineering etc.

013.32.1405 turntable bearing load :
Can bear axial load,radial load and tilting moments.


When you used for 013.32.1405 slewing ring, You can used the following grease:
We recommend automatic gear lubrication.In case of hand lubrication,pinion and gear are to be greased sufficiently with grease recommended Such as Castrol,Mobil,Shell and so on. A weekly gear lubrication is recommended.the gear should always have sufficient grease.
