Crossed roller bearing RB2508UUCC0 25x41x8mm price/specification/lubircation,in stock

Crossed roller bearing RB2508UUCC0 25x41x8mm price/specification/lubircation,in stock

RB2508UUCC0 Crossed roller bearing structure:
It consist of outer ring ,inner ring and small roller and spacer.Each roller in a crossed roller bearing is crossed at a 90° angle,which is able to handle the loading force from multiple direction at the same time. RA crossed roller bearing series belong to outer ring split in half, the inner ring whole unit.RB2508UUCC0 Bearing belongs to light and compact type with thinnest possible inner and outer ring.It is suit for place that weight reduction and downsizing are required,such as the hand swiveling unit robots and manipulators.
The ring and roller material are GCr15.

RB2508UUCC0 Bearing dimension specification:

UU:with seal attached on both sides
U:with seal attached on one side
CCO:negative clearance
CO:positive clearance
C1:positive clearance(greater than CO)
Grade: No Symbol normal grade 0
USP:USP grade rotation accuracy
P5: P5 grade rotation accuracy
The delivery time: in stock
The package:vacuum packing and carton

Crossed roller beairng RB2508UUCC0 application:
Industry robot joints
Industry robot swiveling unit
Swiveling table of machining centers
Rotary units of manipulators
Precision rotary tables,
Medical equipment
Measuring instruments
IC Manufacturing machines

RB2508UUCC0 crossed roller bearing features:
1.High rigidity
2.High rotational accuracy
3.Strictly dimension tolerance
4.Smooth rotation
5.Compact ,space saving
6.Easy installation and adjustment
7.Light series

Besides of RB2508UUCC0   ,We can offer RA5008UUCC0,RA6008UUCC0,RA8008UUCC0,RA7008UUCC0,RA9008UUCC0,RA11008UUCC0,RA12008UUCC0,RA10008UUCC0,RA13008UUCC0,RA14008UUCC0,RA15008UUCC0,RA16013UUCC0,RA170013UUCC0,RA18013UUCC0,RA19013UUCC0,RA20013UUCC0 , RB2008UUCC0 and customized crossed roller bearing type.

About the crossed roller bearing RB2508UUCC0 Installation and lubrication:
For the RB2008UUCC0 Bearing we had filled in the good No.2 Li Base grease into them,then it can be directly mounted after receiving the RB2508UUCC0  Bearing.But compared with other conventional roller bearing,the internal space is smaller,so regular refill the grease is necessary.

The grease is entering into the oil holes which in the ring and connected with oil gap.The intervals are usually six months in one year.Please use the same grease to fill into the RB2508UUCC0  Bearing.
But note that,because of the resistance of grease,the torque moment will increase in a short time the the beginning period.After redundant grease overflows from the seals ,It will recover the normal torque value.

YRT series rotary table bearing product as follows:
