RKS.23 0741 F slewing bearing 634x848x56mm ball bearing without gear

RKS.23 0741 F slewing bearing 634x848x56mm ball bearing without gear

RKS.23 0741      Single row four-point contact ball slewing bearings

Dimensions - d (inside diameter): 634 mm

Dimensions - D (outside diameter):848 mm

Dimensions - B (width): 56 mm

RKS.23 0741  Single row four-point contact ball slewing bearings are simple in design. They are particularly versatile and offer many advantages for applications where there are light-tomedium axial, radial and moment loads.
RKS.23 0741     The outer ring and inner ring material: 42CrMo, 42CrMo4V,50Mn in accordance with EN 10083
Ball material: 100Cr6 bearing steel,in accordance with EN ISO683
Geart teeth accuracy grade: in accordance with ISO1328
Oil or grease material:Lithium grease
The inner ring and outer ring Material  hardness: quenching and tempering: HB229~269
Raceway case hardening :HRC55~62
RKS.23 0741  The package,: Inside packaging: plastic film + kraft paper + blue tape; Outside packaging: standard export free-fumigation wooden case. we can assure that the bearing shipping by sea or by air.
The delivery time:25-35 days

Generally, RKS.23 0741   slewing bearings are large-size rolling bearings that can accommodate axial, radial and moment loads acting either singly or in combination and in any direction. They can perform both slewing (oscillating) movements as well as rotational movements.
Basically, RKS.23 0741 slewing bearing consists of an inner ring , an outer ring and rolling elements−balls or cylindrical rollers−that are separated by polyamide spacers .The rings, one of which usually incorporates a gear , are provided with holes to accommodate attachment bolts. The holes may be threaded.

Generally, only the raceways in the rings are hardened and precision- ground. Integral seals  made of acrylonitrile- butadiene rubber (NBR) keep the lubricant in, and contaminants out of the bearing.

Main Types:
Single row ball slewing ring bearings
Double row ball slewing ring bearings
Crossed roller slewing ring bearing
Three row cylindrical roller slewing bearings
BALL & ROLLER combined slewing bearings
Flanged slewing ring bearing
Gear Type:
Slewing bearings with external gear
Slewing bearings with internal gear
Slew bearings without gear
Flange type:
Slewing bearings with external flange and internal gear
Slew rings with internal flange and external gear
Slew bearings with external and internal flange

RKS.23 0741    Slewing bearings perform extremely well in a variety of applications such as:
• access platforms
• bucket wheel excavators
• conveyor booms
• cranes of all types
• small, medium and large excavators
• indexing tables
• ladle turrets
• offshore applications
• robots
• railway bogies
• rotary platforms
• stackers
• solar mirrors
• tunnel boring machines
• wind turbines
