Screen With Circle Throw Use Roller Bearing 23040 CCK/W33 200x310 X82mm
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Ring Material: | GCr15SiMn | Roller Material: | GCr15 |
|---|---|---|---|
| Number Of Row: | Double Row | Cage Material: | Steel Or Brass Available |
| Full Size: | 200*310*82mm | Shaft Diameter: | 200mm |
| Clearance: | C1 C2 C0 C3 C4 | Delivery Time: | In Stock |
Screen With Circle Throw Use Roller Bearing 23040 CCK/W33 200x310 X82mm
| Product Name: | spherical roller bearing |
| Model: | 23040 CCk W33 |
| Old model: | 23040 cckw33 tapered bore |
| Price: | USD100 to 2000 |
| Min qty: | 2PCS |
| Stock: | 5000pcs |
| Production Capacity: | 200000PCS/Month |
| Payment term: | T/T,WU,LC |
| Delivery time: | In stock |
| Shipping Ways: | By sea by air FedEx/DHL,UPS available |
| Port: | Shanghai /Qingdao seaport |
| Transport Package: | Carton+Wooden case |
| Country of Origin: | China |
| Structure: | Double row spherical roller bearing |
| Number of Rows: | 2 rows |
| Units: | mm |
| Inside Diameter: | 200mm |
| Outside Diameter: | 310mm |
| Thickness/Width: | 82mm |
| Boundary: | 200*310*82mm |
| HS Code: | 8482300000 spherical roller bearing |
| Application: |
Wheel Continuous casters Screw conveyors Grinding mills Press rolls Gear shafts Drying cylinders Conveyor pulleys Roller tables Calanders Crushers Propulsion equipment Flour mills Gear shafts Felt rolls Wire rolls Industrial fans Blowers Agricultural machinery Gear shafts Suction rolls Vibrating screen Washing machinery Crank press Shredders Chippers Industrial lawn mowers Large electric motors Crushers Blowers Mixers Harvesters Pumps Paper dryers Heated calenders Cookers Mixers Yankee drying cylinders Heat exchangers
|
C2 Radial internal clearance smaller than Normal
C3 Radial internal clearance greater than Normal
C4 Radial internal clearance greater than C3
C5 Radial internal clearance greater than C4
C08 Increased running accuracy to ISO tolerance class 5
C083 C08 + C3
C084 C08 + C4
2CS Sheet steel reinforced contact seal of acrylonitrile-butadiene rubber
(NBR) on both sides of the bearing. Grease fill 25 to 35 % with SKF LGEP 2 grease. Annular
groove and three lubrication holes in the outer ring.
2CS2 Sheet steel reinforced contact seal of fluoro rubber (FKM) on both sides of the bearing. Grease fill 70
to 100 % with a polyurea high temperature grease. Annular groove and three lubrication holes in the outer ring
2CS5 Sheet steel reinforced contact
seal of hydrogenated acrylonitrile-butadiene rubber (HNBR) on
both sides of the bearing. Grease
fill
70 to 100 % with a polyurea high
temperature grease. Annular
groove and three lubrication holes
in the outer ring
HA3 Case hardened inner ring
K Tapered bore, taper 1:12
K30 Tapered bore, taper 1:30
P5 Dimensional and running accuracy to ISO tolerance class 5
P6 Dimensional and running accuracy to ISO tolerance class 6
P62 P6 + C2
VA405 Bearing for vibratory applications
VA406 Bearing for vibratory applications
with PTFE-coated bore
VE552(E) Outer ring with three equally
spaced threaded holes in one side
face to accommodate hoisting
tackle; the E indicates that appropriate eye bolts are supplied with
the bearing
VE553(E) Outer ring with three equally
spaced threaded holes in both
side faces to accommodate
hoisting tackle; the E indicates
that appropriate eye bolts are
supplied with the bearings
VG114 Surface hardened pressed steel
cages
VQ424 Running accuracy better than
C08
VT143 Grease fill 25 to 35 % with SKF
LGEP 2 grease
W No relubrication facility in the
outer ring
W20 Three lubrication holes in the
outer ring
W26 Six lubrication holes in the inner
ring
W33 Annular groove and three lubrication holes in the outer ring
W64 Solid Oil filling
W77 Plugged W33 lubrication holes
W513 W26 + W33
